The All-New Scott Spark is the perfect blend of top-notch carbon engineering, never before seen levels of integration and just the right amount of secret sauce. Scott wanted to make this platform faster than ever before both up and down the hill. increasing travel, perfecting geometry, and applying input from the world's best athletes, we've created the cross-country race bike of all cross-country race bikes. if you think fast is fun, then you're going to love this ride.
Take a look at our full range of Scott Spark here at My Ride.
WHAT'S NEW
- Frame with Intergrated Suspension Technology
- 120mm Travel
- Syncros Cable Integration System
- Fox Nude 5
- TwinLoc
- Shimano XT
- Race Face Carbon Crankset
- Syncros Parts
Integrated suspension technology
- The All-New Spark features our patented Integrated Suspension Technology. Not only does this make for a fantastic looking bike, but it allows us to really improve the bikes suspension performance. Scott has engineered frames with a lower shock placement, which lowers center of gravity. The result is better handling, and a more stable, confidence inspiring ride for the end user. It will also keep your shock protected from the elements when the weather and track turn sour!
Evolap carbon technology
- Scott has engineered the Spark to have two main construction zones - a stiffness zone and a lightweight zone. Through strategic carbon reinforcement in the stiffness zone, Scott can afford to really shave weight in the lightweight zone. Some areas of the frame have less thickness than a credit card!
Syncros Fraser IC
- The New Spark features an all-new Fraser IC combo from Syncros. Integrating the cables presents a number of unique problems and the Fraser was designed in part to address this issue. Syncros designers worked on the shape to allow the cables to flow under the bar and around the sides of the stem before disappearing into the headset with integrated plastic parts to keep it clean and efficient. This avoids bends or kinks in the cables and provides a minimalist front end. All of the bars and stems feature multiple options for computer, light and camera mounts both on top or under the bar.
Cross-country geometry
- Looking at the frame layout in general, Scott took years of feedback from the World's fastest athletes to develop the new Spark RC's Geometry. One of the main goals for the bike was to have a platform designed around 120mm of suspension travel front and rear. Having more suspension travel for the increasingly technical racetracks was a priority. The result is the most capable XC race bike ever, and the lightest on the market with 120mm of suspension front and rear coming in at just 1870g with shock.
Working with athletes like Nino Schurter, Kate Courtney and the rest of the SCOTT SRAM MTB Racing Team, Scott was able to pinpoint exactly what they wanted in terms of Geometry. Scott wanted the most dynamic of XC bikes, so they aimed to have a geometry solution that sacrificed nothing in terms of efficiency when you need to put the power down or fly up technical climbs, while giving athletes a safe, confidence inspiring ride on the way down. From what we're told, Scott's hit that nail squarely on the head.
Twinloc suspension system
- The Spark features our TwinLoc Suspension System. The TwinLoc Suspension System is a proprietary SCOTT Suspension System that works by connecting the shock, fork, and ultimately the frame via a handlebar remote. With the remote, the user has the ability to choose from three ride modes, Descend, Traction Control and Lockout, effectively changing the bikes geometry, suspension damping and spring curve simultaneously. Scott's new lever also features the dropper post actuation below the bar. This ergonomic solution puts all of the bike's controls in one place making them easily accessible on the fly.
Devil in the details
- Many other small details truly make the Spark RC THE bike to have. It has room for two water bottles, and integrated axle tool, and very clever frame protection amongst other things! Our development team really made sure to maximize value with this bike, and in that they have succeeded!
Syncros Fraser 2.0 XC Alloy 6061 D.B. Flat Bar / 8degrees / 740mm Syncros Pro lock-on grips
Syncros - Acros Angle adjust & Cable Routing HS System +-0.6degrees head angle adjustment ZS56/28.6 – ZS56/40 MTB
SCOTT TwinLoc 2 Technology 3 Suspension modes
Syncros Belcarra Regular 2.0 CRMO rails
Syncros Duncan 2.0 / 10mm offset 31.6x400mm
Syncros XC 2.0 Syncros Cable Integration System -12degrees rise / 6061 Alloy / 31.8mm / 1 1/8
SCOTT TwinLoc 2 Technology 3 Suspension modes
Race Face BB92 Ø30mm / Double Row / Ext. Seal
Shimano XT M8100 Disc
Shimano SM-RT66 / 6 Bolt / 180/F and 160/R
Shimano SLX CS-M7100-12 / 10-51 T
Shimano SLX CN-M7100
Race Face Next R Carbon crankarm 143 Spindle / 55mm CL / DM32T SHI
Shimano XT RD-M8100 SGS Shadow Plus / 12 Speed
12 speed
Shimano XT SL-M8100-IR / Rapidfire Plus Ispec EV clamp
FOX 34 SC Float Performance Air Grip 3 3-Modes / Kabolt 15x110mm axle / 44mm offset / tapered steerer Reb. Adj. / Lockout / 120mm travel
Spark RC Carbon HMF Integrated Suspension Technology Flex Pivot / Adjustable head angle Syncros Cable Integration System BB92 / UDH Interface / 12x148mm with 55mm Chainline
Carbon
120mm
FOX NUDE 5 EVOL Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend DPS / Reb. Adj./ Travel 120-80-Lockout / T165X45mm
120mm
FOX 34 SC Float Performance Air Grip 3 3-Modes / Kabolt 15x110mm axle / 44mm offset / tapered steerer Reb. Adj. / Lockout / 120mm travel
11.7 (Tubless setup)
Transport Axle
Maxxis Rekon Race / 29x2.4 / 60TPI Foldable Bead Tubeless Ready / EXO
Maxxis Rekon Race / 29x2.4 / 60TPI Foldable Bead Tubeless Ready / EXO
Syncros Silverton 2.5-30 6 Bolt F: 15x110mm R: 12x148mm 30mm Tubeless ready rim / 28H / Micro Spline Syncros Axle w/Removable Lever with 6mm Allen T30 and T25 Tools
29
*Please note product specifications are subject to change.
